MMA 200E/251E
MMA Welder / IGBT Inverter Stick Welder
- Equipped with RILAND’s self-developed RICHI chip and use the latest high grade IGBT technology.
- Suitable for working with Ø2.5/3.2mm stick electrodes;
- Integrated design of power switch and adjustment knob;
- Adaptable to a broad range of mains voltage;
- Automatic air cooling;
- High cost effectiveness;
| Model | | |
| Input voltage (V) | 1PH 220V (±15%) | 1PH 220V (±15%) |
| Frequency | 50/60Hz | 50/60Hz |
| Rated input current (A) | 26.5 | 32 |
| No-load voltage (V) | 54 | 55 |
| Duty cycle (40℃) | 15% | 20% |
| Output current range (A) | 30-140 | 35-160 |
| Output voltage range (V) | 21.2-25.6 | 21.4-26.4 |
| Efficiency | 85% | 85% |
| Power factor | 0.71 | 0.65 |
| Protection grade | IP21 | IP21 |
| Insulation class | Class F | Class F |
| Anti-shock protection | Class I | Class I |
| Electromagnetic Compatibility (EMC) | A | A |
| Cooling method | Forced air cooling | Forced air cooling |
| Net weight (kg) | 2 | 2.5 |
| Dimensions (L×W×H) (mm) | 204×87×146 | 255×100×176 |
Welding cable quick connector, 2pcs
Allen key, 1pc
Shoulder strap
Ground clamp & cable assembly
Hand-held welding shield
Electrode holder & cable assembly
Welding gloves
Welding chipping hammer
Handheld welding case
